OPERATING CONDITIONS
- Liquid temperature up to 35°C (for home use according to EN 60335-2-41)
Temperature max. liquid: 35°C (for other uses)
- Ambient temperature up to 40°C
- Total suction lift up to 8 mt.
- Continuous duty
MOTOR
- Single-phase 230V-50Hz
- Three-phase 230/400V-50Hz
- Two-Pole induction motor (n = 2850 min-1)
- Insulation Class F
- Protection IP 44
MATERIALS
- Pump body Stainless Steel AISI 304
- Motor Support Aluminium
- Impeller (80-85) Noryl
- Impeller (88) Stainless Steel AISI 304
- Diffuser Noryl
- Pump flange Stainless Steel AISI 304
- Shaft with rotor Stainless Steel AISI 304
- Mechanical seal Ceramic/Graphite/NBR
